Mode Field Conversion FA (MFD FA)

Product Attributes

Model No.: MFD FA

Brand: Fibercan

place of origin: China

Packaging & Delivery

Product Description

Mode Field Conversion Fiber Arrays provide a low-loss coupling solution for waveguides with smaller mode field diameters (MFD). For example, the process involves splicing a 3.2μm MFD fiber to a standard 8.6μm MFD fiber to achieve efficient mode field conversion. By utilizing high-precision V-grooves and proprietary assembly techniques, fibers with different MFDs are securely aligned and fixed in the array. This ensures superior reliability throughout the mode field conversion process.

Features

◆Simplified structure enables direct interfacing with laser diodes and optical fiber links

◆Supports fibers with various numerical apertures (MFD: 3μm/3.5μm/4μm/6.4μm, etc.)

◆Scalable from single-channel to multi-channel (1×N) configurations

◆Compliant with GR-1209, GR-1221 & RoHS

Applications

◆Multi-Channel Optical Integrated Transceiver Module

◆Optical Waveguide Coupling
